53211A D1050-2.57/0.97 Centrifugal Blower

Tag No.：53211A

Model：D1050-2.57/0.97

Name：Centrifugal Blower

Design technical parameters of blower:

Model Selection results:

Blower model		D1050-2.57/0.97
Structural type		Cylinder quantity	1
		Number of cooling	0
		Stage	3
Arrangement form		Motor + transmission + blower
Rotate speed of blower (r/min)		4900
Shaft power (KW)		2700
Maximum outside diameter of impeller (mm)		1160
Weight	Rotor (kg)	~1092
	Air blower (kg)	~24500
Dimensions (length × width × height) mm		~7200×2260×2500
Rotor material	Front and rear disks of the impeller	15MnNiCrMoV
	Impeller blade	15MnNiCrMoV
	Main shaft	35CrMo
Stator material	Machine shell	HT250
	Baffle	HT250
