53210A D1100-3.0/2.1 Centrifugal Blower

ꄴPrevious： 53211A D1050-2.57/0.97 Centrifugal Blower
ꄲNext： 53209A D850-2.3/1.35 Centrifugal Blower

Tag No.：53210A

Model：D1100-3.0/2.1

Name：Centrifugal Blower



Design data:

Medium: process gas

Medium composition (V%):

Inlet flow (m3/min): 1111

Inlet pressure (KPa): 210

Inlet temperature (℃): 70

Outlet pressure (KPa): 300

Relative humidity (%):

Gas constant (J/kgk): 465

Adiabatic index K:1. 35

Local atmospheric pressure (KPa): 100



Selection proposal:

Blower model

D1100-3.0/2.1

Blower structure

Structure

Split vertically and horizontally

Stage quantity

3

Intake direction

Down

Discharge direction

Down

Layout form

Blower + speed increaser + motor

Blower speed (r/min)

4800

Shaft power (KW)

2150

Maximum impeller outer diameter (mm)

1160

Weight

Rotor (kg)

1200

Blower (kg)

24000

Dimensions (L*W*H mm)

2530x2330x2450

Rotor material

Wheel disc/wheel cover

FV520B

Impeller

FV520B

Main shaft

35CrMo

Stator material

Machine shell

HT250

Division plate

HT250



For more details, please feel free to contact us by email to sales@wintekgroup.com
