53201A 4-73NO10.8D Centrifugal Blower
Tag No.：53201A
Model：4-73NO10.8D
Name：Centrifugal Blower
Blower technical parameter and requirements
|
Work conditions |
Conveying medium |
|
Air |
|
Inlet flow |
m³/h |
46593 |
|
|
Full pressure |
Pa |
1200 |
|
|
Intake air temperature |
°C |
45 |
|
|
Local atmospheric pressure |
Pa |
98724 |
|
|
Blower performance |
Blower model |
|
4-73NO10.8D |
|
Blower support form |
|
Single suction cantilever |
|
|
Blower inlet and outlet angle |
|
Pending |
|
|
Inlet flow |
m³/h |
46593 |
|
|
Full pressure |
Pa |
1200 |
|
|
Local atmospheric pressure |
Pa |
98724 |
|
|
Blower rotation |
r/min |
960 |
|
|
Shaft power |
KW |
18.1 |
|
|
Full pressure efficiency |
% |
84.7 |
|
|
Transmission form |
|
Direct connection |
|
|
Bearing housing cooling method |
|
Air cooling |
|
|
Bearing lubrication method |
|
Thin oil |
|
|
Lubricant grade |
|
L-TSA32/L-TSA46 |
|
|
Match motor |
Model |
|
|
|
Rate power |
KW |
21 |
|
|
Rate speed |
r/min |
960 |
|
|
Rate voltage |
V |
380 |
|
|
Enclosure rating |
|
IP55 |
|
|
Insulation class |
|
F |
|
|
Whether frequency conversion |
|
Yes |
|
|
Frequency |
|
50Hz |
|
|
Bearing form |
|
Rolling bearing |
|
|
Bearing brand |
|
Havalo |
|
|
Bearing lubrication method |
|
Grease/Oil Lubrication |
|
|
Cooling method |
|
Air cooling |
|
|
Soft connection |
High |
mm |
|
|
Conveying medium |
|
Air |
|
|
Material |
|
Carbon steel |
|
|
Connection type |
|
Flange |
