57104A Hydrogen Expander
Tag No.: 57104A
Name: Hydrogen Expander
|
名称 Name |
26-2 |
27-2 |
16-17-2 |
18-2 |
27a-2 |
18a-2 |
18b-2 |
|
Vapour Fraction |
1.00000000000000 |
1.00000000000000 |
1.00000000000000 |
1.00000000000000 |
1.00000000000000 |
1.00000000000000 |
1.00000000000000 |
|
Temperature [℃] |
-212.200000000000 |
-220.192360383383 |
-30.0000000000000 |
-40.2068330280309 |
-228.635187473816 |
-49.9401464441972 |
-60.0746948774051 |
|
Pressure [bar] |
31.0000000000000 |
18.0000000000000 |
31.0000000000000 |
25.5000000000000 |
9.20000000000000 |
21.0000000000000 |
17.0000000000000 |
|
Molar Flow [Nm3/h(gas)] |
50031.2491953077 |
50031.2491953077 |
30389.3142895496 |
30389.3142895496 |
50031.2491953077 |
30389.3142895496 |
30389.3142895496 |
|
Mass Flow [kg/h] |
4500.00000000000 |
4500.00000000000 |
2733.32999880000 |
2733.32999880000 |
4500.00000000000 |
2733.32999880000 |
2733.32999880000 |
|
Liquid Volume Flow [m3/h] |
64.4153729146672 |
64.4153729146672 |
39.1263269270109 |
39.1263269270109 |
64.4153729146672 |
39.1263269270109 |
39.1263269270109 |
|
Heat Flow [kW] |
-4306.61253349692 |
-4406.82837265062 |
-587.069784806186 |
-697.063549639143 |
-4512.46841174312 |
-801.552887001508 |
-909.988563887694 |
|
名称 Name |
1 |
2 |
22-2 |
22a-2 |
22b-2 |
21-2 |
22c-2 |
|
Vapour Fraction |
1.00000000000000 |
1.00000000000000 |
1.00000000000000 |
1.00000000000000 |
1.00000000000000 |
1.00000000000000 |
1.00000000000000 |
|
Temperature [℃] |
-237.488391379706 |
-245.948993632130 |
-158.655168208275 |
-170.572868710757 |
-180.612225631679 |
-148.000000000000 |
-189.259829573844 |
|
Pressure [bar] |
3.80000000000000 |
1.21300000000000 |
19.0000000000000 |
10.8000000000000 |
6.50000000000000 |
31.0000000000000 |
4.00000000000000 |
|
Molar Flow [Nm3/h(gas)] |
50031.2491953077 |
50031.2491953077 |
36475.0042922436 |
36475.0042922436 |
36475.0042922436 |
36475.0042922436 |
36475.0042922436 |
|
Mass Flow [kg/h] |
4500.00000000000 |
4500.00000000000 |
3280.70000160000 |
3280.70000160000 |
3280.70000160000 |
3280.70000160000 |
3280.70000160000 |
|
Liquid Volume Flow [m3/h] |
64.4153729146672 |
64.4153729146672 |
46.9616697831585 |
46.9616697831585 |
46.9616697831585 |
46.9616697831585 |
46.9616697831585 |
|
Heat Flow [kW] |
-4628.82379532578 |
-4749.88076195878 |
-2368.96036250544 |
-2513.23735329289 |
-2635.62341528605 |
-2240.76947824486 |
-2741.54927988031 |
|
名称 Name |
5-2 |
5a-2 |
5b-2 |
4-2 |
3 |
6 |
4 |
|
Vapour Fraction |
1.00000000000000 |
1.00000000000000 |
1.00000000000000 |
1.00000000000000 |
1.00000000000000 |
1.00000000000000 |
1.00000000000000 |
|
Temperature [℃] |
-95.4199783543866 |
-103.692398118150 |
-114.748854744067 |
-86.0000000000000 |
-130.717929429537 |
-198.713381100232 |
-207.866618403598 |
|
Pressure [bar] |
7.00000000000000 |
5.55000000000000 |
3.95000000000000 |
9.18660000000000 |
2.30000000000000 |
2.20000000000000 |
1.21300000000000 |
|
Molar Flow [Nm3/h(gas)] |
30389.3142895496 |
30389.3142895496 |
30389.3142895496 |
30389.3142895496 |
30389.3142895496 |
36475.0042922436 |
36475.0042922436 |
|
Mass Flow [kg/h] |
2733.32999880000 |
2733.32999880000 |
2733.32999880000 |
2733.32999880000 |
2733.32999880000 |
3280.70000160000 |
3280.70000160000 |
|
Liquid Volume Flow [m3/h] |
39.1263269270109 |
39.1263269270109 |
39.1263269270109 |
39.1263269270109 |
39.1263269270109 |
46.9616697831585 |
46.9616697831585 |
|
Heat Flow [kW] |
-1285.82025767766 |
-1373.42465530767 |
-1490.34629085629 |
-1185.97883177620 |
-1659.00381876704 |
-2857.96858648715 |
-2971.63905106391 |
|
名称 Name |
5 |
7 |
8 |
9 |
10 |
|
|
|
Vapour Fraction |
1.00000000000000 |
1.00000000000000 |
1.00000000000000 |
1.00000000000000 |
1.00000000000000 |
|
|
|
Temperature [℃] |
-139.877584865837 |
-149.401509099847 |
-68.9929058240847 |
-77.6523439771989 |
-87.0851132275671 |
|
|
|
Pressure [bar] |
1.70000000000000 |
1.21300000000000 |
14.0000000000000 |
11.5000000000000 |
9.18700000000000 |
|
|
|
Molar Flow [Nm3/h(gas)] |
30389.3142895496 |
30389.3142895496 |
30389.3142895496 |
30389.3142895496 |
30389.3142895496 |
|
|
|
Mass Flow [kg/h] |
2733.32999880000 |
2733.32999880000 |
2733.32999880000 |
2733.32999880000 |
2733.32999880000 |
|
|
|
Liquid Volume Flow [m3/h] |
39.1263269270109 |
39.1263269270109 |
39.1263269270109 |
39.1263269270109 |
39.1263269270109 |
|
|
|
Heat Flow [kW] |
-1755.71816758821 |
-1856.22103236350 |
-1005.14658284792 |
-1097.33949082635 |
-1197.56808098402 |
|
|
For more information, please contact us by email sales@wintekgroup.com
