58304A CWB32-75 Magnetic Vortex Pump

Tag No.:58304A

Model:CWB32-75

Name:Magnetic Vortex Pump



1. P-7200A/B data sheet



Magnetic pump data sheet



User name





Project name





Revision



User information

Model

CWB32-75

Pump type

√OH1 □OH2 □BB4 □others

Name



Tag

P-7200A/B

Category

Magnetic vortex pump

Qty

(set)

2

Work



Standby



Medium features

Work conditions

Name



Temp

()

Normal

44

Min



Max



Main composition



Input

pressure (MPa)

Normal



Min



Max



Composition concentration



Output

pressure (MPa)

Normal



Min



Max



Medium features

□None □toxic □corrosive □explosive

Pressure difference

(MPa)



Solids

content



Head

(m)

70

Density

(kg/m3)



Flow

(m3/h)

Normal

2.4

Rated



Max



Viscosity

(cP)



NPSHa (m)



Saturated vapor pressure

KPa(A)



Work mode

√Continuous □discontinuous

Local conditions

Ambient temp

()

Min



Normal



Max



Installation location

□Indoor □outdoor □outdoor with shed

Relative humidity

(%)

Min



Average



Max



On-site environment

□Normal □corrosion □toxic □dust

Atmospheric pressure

101(KPa)

Altitude

(m)



Product information

Pump performance

Main construction

Flow (m3/h)

2.4

Stages

Single

Rated impeller diameter (mm)

105

Head (m)

70

Pump jacket

√None □water jacket □steam jacket □others

Min continuous flow (m³/h)

1.4

Shell layout form

√Horizontal □vertical

NPSHr (m)

2

Shell installation method

√Foot installation □centerline installation

Efficiency (%)

22

Shell split type

√Radial split □horizontal split

Shaft power (KW)

2.07

Shell structure type

√Single volute □double volute

□guide vane

Speed (r/min)

2900

Shell wear ring

□Yes √no

Pump body design pressure (MPa)

1.6

Impeller suction type

√Single suction □double suction

Pump body test

pressure (MPa)

2.4

Impeller

structure type

√Closed □semi-open □open

Major parts materials

Shell cutting hole

√Output liquid □Output gas □instrument

Pump

body

304

Bearing seat

304

Coupling type

√None □diaphragm □others

Impeller

304

Pump cover

304

Start method

√Manual start □automatic start

Isolation sleeve

304

Pump shaft

304

Rotation direction

√Clockwise □counterclockwise

Flange dimensions

Main

nozzles

Name

Nominal dimensions

Pressure grade

Seal

surface

Flange standard

Input nozzle

32

PN16

RF

HG/T 20592-2009

Output nozzle

32

PN16

RF

Auxiliary system

Motor parameters

Auxiliary

system type

√None □leak detection

□temperature detection □filter

Manufacturer



Leakage detection

type

□Liquid □gas

Model



Rated voltage (V)

380

Temp

detection type

□Single □double

Power (KW)

5.5

Frequency (Hz)

50

Detection location

□Pump body □isolation sleeve

□bearing body

Poles

2

Explosion-proof grade, protection grade

dⅡBT4

Filter type

□Magnetic □composite

Phases

3

Protection grade

IP55

Motor

auxiliary

type

□Current protector □power

protector

Installation

method

B35

Insulation grade

F

Quality

Rotation direction

√Clockwise □counterclockwise

Synchronous

speed (r/min)

2900

Total mass (kg)



Pump



Motor



Start method

√Direct start □star/triangle depressurization start □soft start



For more details, please feel free to contact us by email to sales@wintekgroup.com



Key Words: Magnetic Vortex Pump, Vortex Pump, Magnetic Pump
